Rear View Camera
AOTOP Offers Various Rear View Cameras for Vehicle Reversing Safety！
ALL REAR VIEW CAMERAS
The Best View When Reversing
AOTOP specialises in the research, development, and production of rear view camera, dedicated to providing high-quality, reliable rear view camera solutions for global users. Leveraging years of industry experience and a comprehensive production system, our products are widely applied across various sectors, including passenger vehicles, commercial vehicles, and construction machinery. AOTOP offers a variety of specifications and installation options for rear view camera, including wired and wireless, high-definition night vision, waterproof and dustproof features, to meet the needs of different vehicle models and usage environments. Whether it’s upgrading a personal vehicle or deploying a fleet on a large scale, we can provide efficient, customised solutions. Please contact us at sales@aotop.com.
| » Model | AC-301 |
|---|
Features
- CVBS / 1080P AHD Resolution Optional
- SONY CCD / CMOS Image Sensor
- IP69K Waterproof Level
- 120° Wide Angle
- 18pcs IR LED Lights (with Light Sensor, AUTO Night Vision)
- Infrared Distance 8-10M
- Optional PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-302 |
|---|
Features
- CVBS / 720P 1080P AHD Resolution Optional
- SONY CCD / CMOS Image Sensor
- IP69K Waterproof / Dustproof
- 120° Wide Angle
- 18pcs IR LED Night Lights (AUTO)
- Infrared Distance 8-10M
- PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-303 |
|---|
Features
- CVBS / 720P 1080P AHD Resolution Optional
- SONY CCD / CMOS Image Sensor
- IP69K Waterproof Rated
- 130° Wide Angle
- 12pcs IR LED Night Lights (Light Sensor AUTO ON/OFF)
- PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- LOGO / Label
* MOQ Requirements
| » Model | AC-305 |
|---|
Features
- Sunshade Movable Bracket
- CVBS & 720P 1080P AHD Resolution Optional
- SONY CCD / CMOS Image Sensor
- IP69K Waterproof Dustproof
- 120° Wide Angle
- 17pcs IR LED Night Lights (AUTO)
- PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-330D |
|---|
Features
- CVBS / 1080P AHD Resolution Optional
- SONY CCD / CMOS Image Sensor
- IP69K Waterproof Level
- Horizontal: 90°/60°, Vertical: 70°, Diagonal: 100°
- 18pcs IR LED Lights (with Light Sensor, AUTO Night Vision)
- Infrared Distance 8-10M
- Optional PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-330S |
|---|
Features
- CVBS / 1080P AHD Resolution Optional
- CMOS Image Sensor
- IP69K Waterproof Level
- 120° Wide Angle
- 15pcs IR LED Lights (with Light Sensor, AUTO Night Vision)
- Infrared Distance 8-10M
- Optional PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-972 |
|---|
Features
- Stainless Steel Bracket
- 720P / 1080P AHD Resolution
- CMOS Image Sensor
- IP69K Waterproof Ratio
- 130° Wide Angle
- 6pcs IR LED Lights (with Light Sensor, AUTO Night Vision)
- Wide Dynamic Range Technology
- Optional PAL / NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-661 |
|---|
Features
- 720P 1080P AHD Resolution Optional
- CMOS Image Sensor
- With Auto Shutter for Better Protection of Lens, Suit to Use in Bad Environment Such As Sandy or Heavily Snowy Weather
- IP69K Waterproof Level
- 130° Wide Angle
- 12pcs IR LED Lights (with Light Sensor, AUTO Night Vision)
- Infrared Distance 8-10M
- Optional PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-331 |
|---|
Features
- CVBS / 720P 1080P AHD Resolution Optional
- SONY CCD / CMOS Image Sensor
- IP68 Waterproof Level
- 120° Wide Angle
- 10pcs IR LED Night Lights (AUTO-ON/OFF)
- Optional PAL & NTSC TV System
- Aviation 4PIN Female / RCA Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-976 |
|---|
Features
- Stainless Steel Bracket
- 720P / 1080P AHD Resolution
- CMOS Image Sensor
- IP69K Waterproof Ratio
- 130° Wide Angle
- 6pcs IR LED Lights (with Light Sensor, AUTO Night Vision)
- Wide Dynamic Range Technology
- Optional PAL / NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <160mA
- Power Consumption: <2.2W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-982 |
|---|
Features
- 720P / 1080P AHD Resolution
- CMOS Image Sensor
- IP69K Waterproof Ratio
- 120° Wide Angle View
- Built-in Top Starlight Night Vision
(with Light Sensor, AUTO Night Vision) - Optional PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- Lens Heating
- LOGO / Label
* MOQ Requirements
| » Model | AC-983 |
|---|
Features
- 720P / 1080P AHD Resolution
- IP69K Waterproof Level
- CMOS Image Sensor
- 120° Wide Angle
- 4pcs Unique LED Night Lights (with Light Sensor, AUTO-ON/OFF)
- PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- LOGO / Label
* MOQ Requirements
| » Model | AC-206 |
|---|
Features
- 720P / 1080P AHD Resolution
- CMOS Image Sensor
- IP69K Waterproof Ratio
- 120° Wide Angle View
- Built-in Top Starlight Night Vision
(with Light Sensor, AUTO Night Vision) - Optional PAL & NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <250mA
- Power Consumption: <3W
Customization Options
- Angle View
- Mounting Bracket
- Microphone Audio
- Connector Type
- LOGO / Label
* MOQ Requirements
| » Model | AC-980 |
|---|
Features
- 720P / 1080P AHD Resolution
- CMOS Image Sensor
- IP69K Waterproof Level
- Diagonal 117° View
- Built-in Top Starlight Night Vision
- Wide Dynamic Range Technology
- Optional PAL / NTSC TV System
- Aviation 4PIN Female Connector
Power Consumption
- Power Supply: 12V
- Maximum Current: <100mA
- Power Consumption: <1W
Customization Options
- Angle View
- Microphone Audio
- Connector Type
- LOGO / Label
* MOQ Requirements
| » Model | CH307B2 |
|---|
Features
- 1080P AHD Resolution
- CMOS Image Sensor
- IP69K Waterproof Ratio
- 130° Wide Angle
- Built-in Top Starlight Night Vision
(with Light Sensor, AUTO Night Vision) - Optional PAL & NTSC TV System
- Aviation 4PIN Female Connector
- Wide Dynamic Range Technology
Power Consumption
- Power Supply: 12V
- Maximum Current: <100mA
- Power Consumption: <1W
Customization Options
- Angle View
- Microphone Audio
- Connector Type
- LOGO / Label
* MOQ Requirements
What is Rear View Camera System and Its Role in Vehicle Safety
- A rear view camera system is a visual assistance device mounted at the back of a vehicle to help drivers monitor the rear environment in real time. It typically consists of HD camera and an in-vehicle monitor, transmitting live video footage so drivers can clearly see behind the vehicle when reversing, parking or maneuvering at low speeds.
- Compared with regular mirrors, rear view camera provides a wider field of view and minimizes blind spots, reducing potential safety risks. It is especially valuable for large vehicles such as trucks, buses, trailers and RVs. By enhancing rear visibility, the rear view camera has become an essential part of modern vehicle safety systems, helping prevent collisions, boosting driver confidence, and lowering accident risks.
How Rear View Camera Works
- The imaging process of rear view camera is based on the principle of photoelectric conversion. The scene behind the vehicle passes through the lens assembly to form an optical image, which is projected onto the CMOS image sensor. The sensor converts the light signal into an electrical signal, which is then converted into digital signal through an analog-to-digital converter (ADC). The DSP (digital signal processor) then performs color correction, image compression, and noise reduction, and the real-time image is finally displayed on the monitor.
Installation Method and Precautions for Rear View Camera
- When installing rear view camera on commercial vehicle, the choice of location and wiring method is especially important. Due to the long body and complex rear structure, the camera should be mounted on the center line or upper rear of the vehicle to ensure a symmetrical view that fully covers the area behind. For vehicles with tailgates or lifting structures, a vibration-resistant and firmly fixed mounting bracket should be used to prevent image deviation caused by vehicle vibration.
- Wiring should follow the vehicle’s original harness route, using shielded video cables and waterproof aviation connectors to prevent electromagnetic interference and water ingress. When cables pass through metal holes, use rubber grommets or protective rings to keep the insulation layer intact. Leave enough slack at bends, hinges or connection points to reduce mechanical tension. The camera’s power can be taken from the reverse signal wire or control module, and a fuse should be added to prevent short circuits.
- In addition, the installation angle should tilt downward about 10~15°, allowing the driver to see the rear and ground distance clearly without glare from light reflection. For vehicles operating at night, it is recommended to use a model with infrared illumination to ensure clear imaging under low-light conditions.
Key Parameters to Consider When Choosing the Best Rear View Camera
- When selecting a rear view camera, it is important to evaluate its imaging performance, protection level, and compatibility to ensure stable operation in different vehicle environments. High quality rear view cameras on the market usually have the following features:
- High resolution, using CMOS image sensor, supporting analog HD output of 720P / 960P / 1080P
- Lens viewing angle generally ranges from 110° to 150°
- Features shockproof, anti-corrosion and high / low temperature resistance
- Waterproof and dustproof rating reaches IP68 / IP69K, unaffected by harsh weather
- Supports mirror image switching and reversing guide lines, adjustable for different installation positions or driving habits
- Equipped with night vision, infrared distance of 7–10 meters, ensuring clear images in low-light or night conditions
How Much Does Aftermarket Rear View Camera Cost
- Installing rear view cameras for your fleet can enhance both driving safety and convenience. While most new vehicles come equipped with a rear view camera, some older models may not have one. If your vehicles lack a camera, you can choose to install one yourself. The price of aftermarket backup cameras varies widely, so it’s important to plan your budget and consider installation costs. Additionally, older vehicles can opt for spare cameras compatible with existing rearview mirrors. Generally, the retail price of rear view cameras ranges from $150 ~ $600. For bulk purchases or long-term cooperation with manufacturers, the price is usually more favorable.
How to Choose Reliable Rear View Camera Brand
- When selecting a rear view camera brand, the focus should be on the manufacturer’s technical capability, quality management system, and comprehensive service capacity. A reliable manufacturer typically holds ISO/TS 16949 automotive quality certification, has complete production inspection processes, mature R&D capabilities, and long-term experience providing solutions for commercial vehicles, buses, and construction machinery projects.
- At the same time, the ability to offer OEM/ODM customization to adapt to different vehicle interfaces and installation structures is a key indicator of the manufacturer’s professionalism. High-quality brands apply stricter standards in material selection and safety design, often using metal protective housings with excellent heat dissipation, and performing high/low temperature, vibration, and drop tests to ensure the camera operates reliably under complex and extreme conditions.
- AOTOP has over 20+ years of experience in automotive electronics manufacturing, with a complete R&D, production and testing system, providing high-standard rear view camera solutions for global commercial vehicles, buses and construction machinery brands. With stable performance, rigorous testing, and professional after-sales support, AOTOP has become a long-term trusted partner for numerous international clients, providing reliable protection for fleet safety operations.
