7 Inch HD LCD Rear View Waterproof Monitor
AOTOP 7 inch HD LCD rear view waterproof monitor features IP68 level waterproof, ensure HD view for open-air operating vehicle in all weather conditions, support 3CH AHD cameras video signal input, provide visual monitoring of three key areas around the vehicle, avoid possible collision accidents. Support multi-language settings for users in different regions of the world.
Our EXP
Years Auto Electronics Industry Experience
Quality
We ensure each product meets strict quality standards, 100% tested.
Customized
With the great R&D, we offer professional OEM & ODM services.
Warranty
Support 2 years warranty service, PRO after-sales technical support.
Features
- IP68 Waterproof & Dustproof, Aluminium Alloy Material Shell
- 1024*RGB*600 IPS LCD Screen, 16:9 Ratio
- 3CH x Cameras Video Signal Input
- Multiple Video Formats Available to Cameras: 720P / 1080P / AHD / Compatibility CVBS
- 3 Trigger Lines Input, Trigger Line Definition, Trigger Delay & Priority Can Be Adjusted Freely;
- Full-Function Remote Control
- Multi-Language Settings
- Horizontal Mirror Image Switching; Image Flip;
- DC 12-24V Wide Voltage
- AUTO Adaptation PAL / NTSC System
| Model | CM-708WAHD |
| Waterproof Rating | IP68 |
| Screen Type & Size | 7 Inch IPS LCD Screen |
| Aspect Ratio | 16:9 |
| Resolution | 1024*R.G.B*600 |
| Brightness | 500cd/㎡ |
| Contrast | 500:1 |
| Viewing Angle | Up 85°, Down 85°, Left / Right 85° |
| Video Input |
Support 3CH AHD 1080P/960P/720P/CVBS Mixed Video Signal Input |
| OSD Menu |
Image Setting, Image Signal Turnover, Blue/Black Screen (No Signal), Multi-Language Setting, Parking Guide Line On/Off, Reset |
| Parking Guide Line |
Each Channel is Controlled Separately (Off As Default) |
| Mirror / Normal Image |
Each Channel is Controlled Separately (Mirror As Default) |
| Trigger | 3CH Trigger Lines |
| System | AUTO Adaptation PAL / NTSC |
| Power Supply | DC 12-24V |
| Currents | 12V/<1A |
| Operating Power | <10W |
| Boot Time | Boot Time |
| Connection Plug (Connector) | Waterproof Aviation Female Connector |
| Operating Temperature | -20°C~+70°C (RH0%-RH90%) |
| Storage Temperature | -30°C~+80°C (RH0%-RH90%) |
| Warranty | 2 Years |
| Certification | E-Mark, UKCA, E24, CE, FCC |
Product Applications
AOTOP 7 inch HD LCD rear view waterproof monitor can be easily applied to various agriculture vehicles and work well with our vehicle HD cameras. It helps drivers see their surrounding clearly and effectively reduce the risk of scratches and accidents.
